24630 Lighting stand
24630-009-55 - black The standard lighting stand constructed from steel tubing has been significantly improved. The new legs with tubing diameter of 1.378" guarantee stability and safety. Lasered bore holes and durable, robust plastic saddle washers improve the coefficient of friction between the legs and braces, and prevent scratching of the finish. A compact clamp with a patented push-button system affords user-friendly stand height adjustment. The locking screw provides additional stability. The integrated M10 thread adaptor can be used to attach the crossbars 213/9 and 21393. Technical details
- Order number: US-24630-009-55
Product data
Base diameter: | 49.606 " |
EAN: | 4016842818280 |
Height: | from 76.968 to 114.764" |
Height adjustment: | locking screw with push-button system |
Leg construction: | tube legs with cross braces |
Material: | steel |
Max. load capacity*: | 44.053 lbs |
Number of legs: | 3 |
Product Category: | Topline |
Rod combination: | 2-piece folding design |
Size when folded: | 62.992" |
Tube end(s): | diameter 1.378", integrated threaded bush M10 for crossbars |
Type: | black |
Weight: | 15.661 lbs |
* With centric loading, on a horizontal surface and without lateral forces (wind, shocks etc.)
